MEOW 55™ – Outdoor Wall-Mounted Digital Signage | IP65 Android

Built for the Outdoors. Designed to Be Seen.

Transform any exterior wall into a dynamic digital communication platform with the MEOW 55™, media mea’s premium commercial-grade outdoor wall-mounted digital signage display.

Engineered for permanent outdoor installations, the MEOW 55™ combines an ultra-bright commercial display, weatherproof IP65 enclosure, projected capacitive (PCAP) multi-touch technology, and Android-powered smart content management to deliver an exceptional interactive experience in virtually any environment.

Whether you’re promoting products, displaying restaurant menus, providing visitor information, offering interactive wayfinding, or generating advertising revenue, the MEOW 55™ is built to operate reliably 24 hours a day, 7 days a week—even in harsh outdoor conditions.

Its slim architectural design integrates beautifully with retail storefronts, shopping centers, restaurants, hotels, entertainment venues, hospitals, educational campuses, airports, transit stations, stadiums, municipalities, and corporate facilities.

Designed for Commercial Outdoor Environments

The MEOW 55™ features a fully enclosed IP65-rated aluminum and galvanized steel housing, protecting internal electronics from rain, dust, humidity, heat, snow, and other challenging environmental conditions.

Its intelligent climate-control system continuously regulates the internal operating temperature using industrial cooling fans and thermostatically controlled heating components, ensuring reliable year-round performance.

Brilliant Sunlight Readability

Unlike conventional indoor displays that become unreadable outdoors, the MEOW 55™ utilizes an ultra-high brightness commercial LCD panel delivering up to 2,500 nits, making content clearly visible even under direct sunlight.

An integrated ambient light sensor automatically adjusts brightness throughout the day to maximize visibility while minimizing power consumption.

Full PCAP Multi-Touch Technology

The optional Projected Capacitive (PCAP) touch screen delivers a premium smartphone-like interactive experience.

Users can easily navigate applications, maps, directories, menus, catalogs, ticketing systems, self-service kiosks, and digital wayfinding with precision and speed.

Features include:

• 10-point simultaneous multi-touch
• Supports bare fingers and thin gloves
• Fast response time
• High touch accuracy
• Palm rejection technology
• Scratch-resistant tempered safety glass
• Commercial-grade durability

Smart Android Platform

Powered by Android, the MEOW 55™ offers a flexible platform for digital signage applications.

Run your preferred CMS software, Android applications, interactive content, cloud dashboards, or custom-developed applications with ease.

Compatible with:

• media mea DS™ CMS
• HTML5 applications
• Web-based dashboards
• Interactive kiosks
• Wayfinding software
• Digital menu boards
• QR code applications
• Advertising platforms
• Cloud-based content management systems

Remote Content Management

Manage one display or thousands remotely from anywhere in the world.

Update promotions, videos, images, emergency messages, schedules, pricing, advertisements, and interactive experiences without visiting the installation site.

Commercial Applications

Perfect for:

• Retail storefronts
• Restaurants & cafés
• Shopping malls
• Corporate buildings
• Hotels & resorts
• Hospitals
• Medical centers
• Schools & universities
• Airports
• Transit stations
• Stadiums
• Theme parks
• Museums
• Government buildings
• Real estate developments
• Outdoor advertising networks
• Smart cities
• Entertainment venues
• Churches
• Parks & recreation facilities

Key Features

• Commercial-grade outdoor digital signage
• Permanent wall-mounted installation
• IP65 weatherproof enclosure
• Android operating system
• Full HD commercial LCD panel
• Ultra-high brightness (2,500 nits)
• Optional 10-point PCAP touch technology
• Anti-glare tempered safety glass
• Automatic brightness adjustment
• Integrated cooling & heating system
• Built-in speakers
• Wi-Fi & Ethernet connectivity
• Remote CMS compatible
• USB Plug & Play
• 24/7 continuous operation
• Portrait or landscape installation
• Commercial aluminum enclosure
• VESA mounting compatible
• Optional 4G/5G connectivity

Technical Specifications

Display

• Screen Size: 55”
• Panel Type: Commercial IPS LCD
• Resolution: 1920 × 1080 Full HD
• Brightness: 2,500 cd/m²
• Contrast Ratio: 5,000:1
• Viewing Angle: 178° / 178°
• Aspect Ratio: 16:9
• Display Colors: 16.7 Million
• Response Time: 8 ms
• Backlight: LED
• Panel Life: 50,000+ hours

Touch Technology (Optional)

• Projected Capacitive (PCAP)
• 10-point Multi-Touch
• Tempered Safety Glass
• Palm Rejection
• High Accuracy
• Fast Touch Response
• Anti-Scratch Surface
• IK10 Impact Resistant Glass

Operating System

• Android 14
• Quad-Core ARM Cortex Processor
• Mali GPU
• 4 GB RAM
• 32 GB Internal Storage
• Expandable Storage via USB

Connectivity

• Wi-Fi
• Bluetooth
• Gigabit LAN
• HDMI
• USB
• RJ45
• Audio Out
• Optional 4G LTE
• Optional 5G
• Optional GPS

Media Support

Supports:

• Images
• Videos
• HTML5
• PDF
• PowerPoint
• RSS Feeds
• Web Pages
• Live Streaming
• Interactive Applications
• Digital Menus
• Wayfinding
• QR Codes

Outdoor Protection

• IP65 Rated
• Waterproof
• Dustproof
• Corrosion Resistant
• UV Resistant Finish
• Anti-Glare Glass
• Temperature Controlled Enclosure

Operating Temperature:

• -30°C to +50°C

Storage Temperature:

• -40°C to +60°C

Humidity:

• 10%–90% RH

Audio

• Integrated Stereo Speakers
• Audio Output

Power

• AC 110–240V
• 50/60Hz
• Energy Efficient Operation
• Automatic Power Recovery

Installation

• Wall Mounted
• Portrait or Landscape
• Heavy-Duty Mounting System
• Commercial Installation Ready

Enclosure

• Powder-Coated Galvanized Steel
• Aluminum Components
• Lockable Service Door
• Security Lock System
• Industrial Cooling System
• Thermostatic Heating System

Optional Accessories

• media mea DS™ Cloud CMS
• 4G LTE Modem
• 5G Router
• Camera Integration
• NFC Reader
• RFID Reader
• QR Scanner
• Thermal Printer
• UPS Backup System
• Custom Branding
• Custom Powder-Coat Colors
• Wall Mount Brackets
• Floor Mount Conversion Kit

Warranty

• 1-Year Limited Commercial Warranty
• Extended Warranty Options Available
• Lifetime Technical Support from media mea

Generate Revenue While You Communicate

The MEOW 55™ is more than an outdoor display, it’s a revenue-generating communication platform. Use it to promote your own products and services, deliver real-time information, or monetize your screen by selling advertising space to local and national brands. When paired with media mea DS™, multiple displays can be managed as a centralized digital signage or advertising network, making the MEOW™ series an ideal solution for retail media networks, smart city deployments, transportation hubs, hospitality, education, healthcare, and enterprise environments.
